Features
• Polypropylene depth media option offers ratings from 0.2um to 70um with high capacity and low pressure drop
• Hydrophilic PES and hydrophobic PTFE membranes available in ratings from 0.03 to 1 micron. Integrity testing assures consistent, highly retentive performance. High tolerance to repeated cleaning and steaming cycles
• Products are manufactured in a controlled environment under a quality management system certified to ISO9001:2015
Applications
• Small-Batch Pharmaceutical, Bio-Technology, and Ophthalmic Products
-Bio-reduction and clarification of ingredients and final products
• Semiconductor and Micro-Electronic fluids, fine chemicals
-Cleaners, solvents, photoresist & developer solutions & process chemicals
• Pilot-Scale Investigations and R&D process development
-Facilitates optimizations and scale-up
Material of Constructions
• Media： PP, PES, PTFE
• Support：PP
• Cage/Core/End： PP
• Sealing： Silicone, EPDM, FKM
Performance
• Max. Temperature：80℃(176℉)
• Max. dP (forward)：5 bar(73 psi) @ 50℃(122℉)
• Pressure：3 bar(44 psi) @ 90℃(194℉)
0.3 bar(4 psi) @ 90°C(194℉) reverse
For more than 40 years, GVS has focused on innovating its products and production processes, constantly improving its development capacity to provide the best products, service and support for its clients.
