Features
• Naturally hydrophilic, no need for pre-wetting
• High flow rate, low DP and long service life
• Excellent integrity provides good particle removal and sterilization efficiency
• Non-contact welding adopted, no adhesives, low extractables
• Excellent chemical compactivity
• Tolerance for in-line steam sterilization
• Gross integrity
Applications
• Large volume parenterals (LVP) injections and antibiotic filtration
• Physiological saline solution and other solvents filtration of microorganism removal
• Pure Water and water-based filtration of microorganism removal
Dimension
•Out Diameter 2,72” (69 mm)
•Length 5” (125 mm)
•10” (254 mm)
•20” (500 mm)
•30” (750 mm)
•40” (1000 mm)
Quality
• Filter Cartridges are manufactured in a clean room environment
• Manufactured according to ISO9001:2015 certified Quality Management System 33
Material of Constructions
•Filter medium Nylon N66
•Support/Drainage PET
•Cage/Core Polypropylene
•Endcap Polypropylene and Insert
Performance
• Max Operating Temperature 80 °C
• Max Operating DP Forward 4.0 bar @ 25 °C
Forward 2.4 bar @ 80 °C
• SIP 125 °C , 30min
For more than 40 years, GVS has focused on innovating its products and production processes, constantly improving its development capacity to provide the best products, service and support for its clients.
