Features
• Low pressure drops and high flow rates
• High filtration efficiency, up to 96%
• Excellent chemical compatibility
• High dirt holding capacity and long service life
Applications
• Food & Beverage
• Chemicals & Oil
• Pharmaceutical
• Process Water Treatment
• Pre-filtration of vent & gas
Dimension
•Diameter 69 mm
•Length 5”, 10”, 20”, 30”, 40”
Food Contact Compliance
• Materials of construction comply with FDA regulations for food and beverage contact use as detailed in the US Code of Federal Regulations 21CFR
• Materials used to produce filter media and hardware meet the specifications for biological safety per USP Class VI-121 °C for plastics
• Filter cartridges passed European Commission Directives (EU10/2011)
• Halal Certified
Material of Constructions
• Media GF
• Support PP
• Core/Cage/End Cap PP
• Seal Material Silicone, EPDM, NBR, FKM, E-FKM
Performance
• Operating Conditions
• Max. Operating Temperature 80 °C
• Max. Operating DP 4.0 Bar @ 20 °C
• 2.4 Bar @ 80 °C
