GVS filter integrity tester is a new-generation device signed according to the latest GAMP guidelines. It combines intelligent technology with high-sensitivity performance and features large-capacity accurate data recording, exporting, and printing functions. The tester’s system is designed for greater stability, making it suitable for most cleanroom environments. The device is lightweight, compact, and ergonomic. Its 10-inch high-definition truecolor touch screen enhances usability and simplifies operation.
Additionally, the equipment complies with GMP guidelines and meets FDA 21 CFR Part 11 requirements for electronic records, and 21 CFR 820.72 for calibration.
Filter Test Methods
-Bubble point Test
-Extensive Bubble Point Test
-Pressure Holding Test
-Diffusion FLow Test
-Water Intrusion Test
-Ultrafitration Membrane Test
Dimension
-Weight: 8.2kg
-Depth x Width x Height: 350mm x 352mm x 178mm (13.78in. x 13.86in. x 7.01in.)
Function Test Methods
-Self-check
-Flow Check Test
-Printer Test
-Network Test
Other Functions
-Anti-backflow device (optional)
-Cleaning function
-Test program transfer functionality
-Set the transfer function
-Rights management transfer function
-Test result output function
-Backup function
Pressure Options
-mbar
-kPa
-psi
-kgf/cm2
Communication Ports
-USB
-RS232C
-Ethernet
-Wireless Ethernet Network (optional)
Test Accuracy
-Upstream Volume Test: ±4%
-Bubble Point Test; ±50mbar
-Diffusion Flow Test: ±4%
-Water Intrusion Test: ±0.01ml
Test Range
-Bubble Point; 100-8000mbar
-Diffusion Flow: 1-1000ml/min
-Water Intrusion: 0.01-100ml/min
Electrical Supply
-Voltage: Automatically adjusted between 100-240V AC , external power supply (including EU, UK, US, AU adaptors)
-Input Frequency: 50/60HZ
-Charging Power: 120W
-Spare Battery (optional)
Operation Conditions
-Operating Pressure: 100-10000 mbar (150psi)
-Dust and Splash Level: IP54, Front is IP65
-Operating Temperature: +5°C to +40°C
-Storage Temperature: -20°C to +70°CRelative Humidity: 10-80%
-Applicable Environment: Above D level
-Usage: Online/Offline (with battery)
For more than 40 years, GVS has focused on innovating its products and production processes, constantly improving its development capacity to provide the best products, service and support for its clients.
