Fitting Option

• NPT-Male

• NPT-F

• Swagelok

• CPCPLC-Male

• CPCPLC-Female

• Hose Barb

• Stepped Hose Barb

• Triclover

Toxicity

• All components meet the specifications for biological

• safety per USP Class VI -121 °C for plastics.

Sanitization/Sterilization

• Autoclavable

Filter Area

• 500 cm²

• 1000 cm²

• 1500 cm²

• 2100 cm²

Food Safety Compliance

Materials of construction comply with FDA regulations for food and beverage contact use as detailed in the US Code of Federal Regulations, 21 CFR. Materials used to produce filter media and hardware are safe for use in contact with foodstuffs in accordance with EU Directives 10/2011.

Maximum Operating Conditions

• Maximum operating pressure

     -Liquid: 5 bar (80psi) at 77°F/25°C

     -Gas: 3.5 bar (60psi) at 77°F/25°C

• Maximum Operating Temperature: 80 °C

• Autoclave at 125 °C, 30 minutes and 25 cycles

• Autoclave at 135 °C, 30 minutes and 15 cycles
