Polycarbonate Track Etched (PCTE) Membrane is recommended for TEM and SEM microscopic testing for Asbestos Monitoring.
GVS Polycarbonate Track Etched (PCTE) Membrane is made from a thin polycarbonate film with precisely defined pores. The proprietary manufacturing process provides increased control over pore size and density for absolute size separation. This unique process ensures the physical properties of each membrane precisely fit specification.
Features and Benefits
- Smooth, thin, glass-like surface is suitable for optical
analysis applications
- PVP treated for hydrophilic wetting.
- Resists chemical staining to ease microscopy
visualization
| Thickness | 8 - 11 μm |
| Optical Properties | Semi-translucent |
| Maximum Operating Temperature | 284°F (140°C) |
| Residual Ash Weight Average | 0.92 μg/cm2 |
| Sterilization | Gamma Irradiation or Ethylene Oxide(EtO) |
| Autoclavable | Yes |
| Wetting Characteristics Hydrophilic | Yes |
| Part No. | Dimensions | Packaging | |
|---|---|---|---|
| 1215611 | 0.2 μm | 25 mm 100/pk | |
| 1215614 | 0.4 μm | 25 mm 100/pk | |
| 1215622 | 0.8μm | 25 mm 100/pk | |
| 1215627 | 1 μm | 25 mm 100/pk | |
| 1215615 | 0.4 μm | 37 mm 100/pk | |
| 1215623 | 0.8 μm | 37 mm 100/pk | |
| 1221302 | 1 μm | 37 mm 100/pk | |
| 1215612 | 0.2 μm | 47 mm 100/pk | |
| 1215617 | 0.4 μm | 47 mm 100/pk | |
| 1215624 | 0.8 μm | 47 mm 100/pk | |
| 1215628 | 1 μm | 47 mm 100/pk |
