CIK-PP Capsule Filter

Description Specifications Ordering information

Product features

● Wide chemical compatibility
● High dirt hold capacity
● High retention
● Thermal bonding
● Non-fiber releasing

Typical Application

● Process Water
● Vinegar
● Aqueous solutions
● Beer, Wine and Spirits
● Juice, Soft Drinks, Edible Oils
● Bulk Chemicals
● Pharmaceutical intermediates

Filtration Area	2.5’’ = 1480 cm² 5’’ = 2650 cm² 10’’ = 5500 cm² 20’’ = 11000 cm² 30’’ = 16500 cm² 40’’ = 22000 cm²
Filter Media	PP
Media Support	PP
End Caps/ lner Core/Outer Cage:	PP
Sealing Method	Thermal Bonding
Maximum Operating Temperature	80°C
Maximum Operating Pressure	5 bar @25°C

Part No.	Pore Size	Application	Sterilization	Size	Fittings	Vent/Drain
CIKPP	0060=0.6μm	G = Gen Purpose	N = Not Sterile	SS = 2.5’’	5TC = 1.5" TC	SS = St/St	Order
	0100=1μm	P= Premier		LL=5’’	2HB = 1/2" HB	HH = HB/HB	Order
	0200=2μm			TE=10’’	4HB = 3/4" HB	SH = St/HB	Order
	0300=3μm			TW=20’’	T2B = 1.5" TC/ 1/2" HB	HS = HB/St	Order
	0500=5μm			TH=30’’	T4B = 1.5" TC/ 3/4" HB		Order
	0700=7μm			FO=40’’	2BT = 1/2"HB/ 1.5” TC		Order
	1000=10μm				2B4 = 1/2"HB/ 3/4" HB		Order
	2000=20μm				4BT = 3/4"HB/ 1.5" TC		Order
	3000=30μm				4B2 = 3/4"HB/ 1/2" HB		Order
	5000=50μm						Order
