GVS Quartz microfiber filters are made with 100% pure quartz microfiber with zero binders. Exhibit greater chemical resistance at high temperatures than glass microfiber. Excellent choice for use in environments with extreme temperature up to 900°C and/or aggressive chemical exposure. Retention loading and air flow permeation similar to glass microfiber filters. Use wherever filters of the highest purity are needed.

Features and Benefits:

Excellent retention of very fine particles

Exceptional chemical and thermal resistance.

Excellent weight and dimensional stability with lowest trace metal content.

High Permeation enables large volume of air to pass through.

Higher temperature stability than glass microfiber filters; up to 900°C.

Excellent chemical stability with practically no filter-mass loss in the presence of acid gases (HCl, SO2, SO3, H2, SO4, NO and NO3).

Membrane:100% pure quartz microfiber

Weight85 g/m2
Thickness440 μm
Retention DOP99.998 %
Part No. Diameter Pore Size Package
FP025D0QF1QUFC01 25mm 1.0μm 100/pk

Order

FP037D0QF1QUFC01 37mm 1.0μm 100/pk

Order

FP047D0QF1QUFC01 47mm 1.0μm 100/pk

Order

FP050D0QF1QUFC01 50mm 1.0μm 100/pk

Order

FP055D0QF1QUFC01 55mm 1.0μm 100/pk

Order

FP070D0QF1QUFC01 70mm 1.0μm 100/pk

Order

FP090D0QF1QUFC01 90mm 1.0μm 100/pk

Order

FP110D0QF1QUFC01 110mm 1.0μm 100/pk

Order

FP125D0QF1QUFC01 125mm 1.0μm 100/pk

Order

FP150D0QF1QUFC01 150mm 1.0μm 100/pk

Order

FP203R0QF1QUFC01 203x254 mm 1.0μm 100/pk

Order
