The GVS polypropylene 47 mm filter holder is designed especially for ultra cleaning and sterilizing liquids under positive pressure. In addition this holder can be used for aseptic sampling of liquids or gases at point-of-use or when samples must be collected and processed on-site.

The polypropylene material allows these holders to be used over a wide temperature range with excellent chemical compatibility. Sealing is achieved by simple hand tightening of the locking ring. The 47 mm In-Line holder has dual support screens, which allow for flow in either direction. The inlet cap design and exterior locking ring allow the unit to be assembled quickly and efficiently without tearing the membrane. 3 O-rings help to prevent leaks with all membranes. The 47 mm can filter up to 1 liter depending upon the viscosity of the sample. The polypropylene holder can withstand temperatures up to 121°C and be autoclaved.

Features & Benefits

Easy to use - unique lock ring design assures proper sealing without damage to the membrane

Easy to clean

Conforms with EPA Method 1311 for Toxicity Characteristic Leaching Procedure, 40 CFR, Part 261, 1991 Hazardous Waste

Compliance Guide

Typical Applications

Point of use sampling

Particulate removal

Used in filtering chromatography solvents

General filtration


Part No. Diameter Housing material Inlet/Outlet QTY Package
1262579 47mm Polypropylene 1/4"NPTM/FLS//1/4"NPTM/FLS 1/pk

Order

1214260 47mm Polypropylene 1/4"NPTM/FLS//1/4"NPTM/FLS 10/pk

Order
